Input voltage

187-253V 5O±5Hz

187-253V 50±5Hz

Input Current

<12A

<21A

Power factor

>0.99

>0.99

Harmonic content

<8.5%

<8.5%

Rated output voltage

48±0.5V

72±0.5V

Rated output current

35±0.5A

40±0.5A

Protective function

Input over voltage, output short circuit, over temperature, etc.

Input over voltage, output short circuit, over temperature, etc.

Conversion efficiency

>93%

>93%

Ripple factor

<1%

<1%

Operating temperature

-25°C~60°C

-25°C ~ 60°C

storage temperature

・30°C~90°C

・30°C~90°C

Seismic rating

QC/T413-2002

QC/T41 3-2002

Insulation withstand voltage

1500VAC

1500VAC

Insulation resistance

>20M

>20M

Protection level

IP67

IP67

CNAJB  can

Yes/optional

Have

External indicator

Yes/optional

no

Charging lock

Yes/optional

None (can be added as required)

12V auxiliary source

Yes/optional

12V/5A

Insertion gun inspection ( CC/CP inspection)

no

Yes/optional
